Specifications
| HAMILTON |
|
| Seats: |
5-6 adults |
| Dimensions:* |
7'5" x 7'5" x 36" (226 cm x 226 cm x 92 cm) |
| Dry Weight: |
826 lbs (375 kg) |
| Total Filled Weight: |
4,996 lbs (2,266 kg) |
| Average Spa Volume: |
393 US gal (1,488 liters) |
| Jet Pumps: |
Pump 1 North America 2-speed/2.5 hp continuous |
| |
Pump 2 North America 1-speed/2.5 hp continuous |
| Total Jets: |
41 |
| Accu-Pressure™ Jets: |
9 |
| Vortex™ Jets: |
4 |
| Mini Vortex™ Jets: |
8 |
| SMT™ Micro Adjustable Jets: |
12 |
| SMT Fluidix™ Jets: |
8 |
| Air Control/Massage Selectors: |
3 Controls /1 Selector |
| Water Purification System: |
CLEARRAY® Active Oxygen |
| Filter: |
Two-stage MicroClean® filter, 20" Slipstream™ Skimmer |
| Circulation Pump: |
2 TheraFlo high-flow pumps & Dynamic Flow Circulation System |
| Electrical Requirements: |
North America (60 Hz): 240 VAC @ 40A, 50A or 60A |
| |
Export (50 Hz): 230 VAC @ 20A, 30A or 40A |
| Lighting: |
Multicolor SunRay™ LED Lighting |
| Stainless Steel Jet Trim: |
41 with stainless steel trim |
| Headrests: |
4 |
| Heater: |
Low Flow 2.7Kw |
| Water Feature: |
1 AquaSheer™ Variable Waterfall |
| Shell Colors: |
Celestite, Platinum, Midnight |
| Cabinetry: |
Vintage Oak, Brushed Gray, Modern Hardwood |
Estimated monthly cost is based on CEC test protocol for standby power consumption only. Test results measured in a controlled environment based on a kilowatt rate per hour of $0.33 (typical-2015-NZ-pricing) and rounded to the nearest dollar. Local and future energy rates, local conditions and individual use will alter these estimated monthly costs. For complete CEC test protocol and
results visit energy.ca.gov. Spa Temperature 101°F / 38°C.
* BHP (brake horsepower) is a maximum value measured by the motor manufacturer with no pump installed.
** Heater warranty varies outside North America Dimensions, capacities and weights are approximate.
Specifications are subject to change without notice.
